How to Start OpenAM and OpenDJ in Separate Docker Contaners

Requeirements

To repordce steps in the following article, Docker and Docker Compose should be installed.

Sample configuration used in the following acticle could be found here

OpenAM Perparation

Create docker-compose.yml file and add OpenAM service:

version: '3.9'

services:
  openam:
    image: openidentityplatform/openam:latest
    ports:
      - "8080:8080"
    hostname: openam.example.com
    volumes:
      - ./persistence/openam:/usr/openam/config

Add OpenAM FQDN to your hosts file on your machine, for example

127.0.0.1   auth.example.com

In the persistence/openam folder OpenAM will store its configuration data

OpenDJ Preparation

Add OpenDJ service to docker-compose.yml file:

  opendj:
    image: openidentityplatform/opendj:latest
    hostname: opendj.example.com
    ports:
      - "1389:1389"
      - "1636:1636"
      - "4444:4444"
    volumes:
      - ./opendj/bootstrap/data/:/opt/opendj/bootstrap/data #initial data
      - ./opendj/bootstrap/schema/:/opt/opendj/bootstrap/schema #schema
      - ./persistence/opendj:/opt/opendj/data #opendj data
    environment:
      - BASE_DN=dc=openam,dc=openidentityplatform,dc=org #should be yours base DN

opendj/boststrap directory should exist on the host machine and contain two subfolders: data - for initial data и schema - schema files.

The files could be found here

If base DN id different from dc=openam,dc=openidentityplatform,dc=org it should be changed in opendj/boststrap/data/samlple.ldif file as well

Start and Configuration

Start Services

Start OpenAM and OpenDJ with the following command:

docker-compose up

You shoudl see the following lines in the logs:

openidentityplatform-docker-openam-1  | 15-Jun-2022 10:09:46.063 INFO [main] org.apache.coyote.AbstractProtocol.start Starting ProtocolHandler ["http-nio-8080"]
openidentityplatform-docker-openam-1  | 15-Jun-2022 10:09:46.133 INFO [main] org.apache.catalina.startup.Catalina.start Server startup in [36437] milliseconds
openidentityplatform-docker-opendj-1  | OpenDJ is started

OpenAM Configuration

After OpenAM and OpenDJ started, open OpenAM url in the browser, for example http://auth.example.com:8080/openam

OpenAM configuration window should appear:

Select Custom Configuraion and press Create New Configuration. Read and accept the licence agreement.

Enter and confirm amAdmin password, then press the Next button.

Leave server settings unchanged and press the Next button.

On the Configuration Data Store Settings step set the following settings:

• Configuration Data Store radiobutton to OpenDJ,
• Set Host Name to opendj, as OpenDJ Docker internal hostname
• Set Port to 1389 as specified for OpenDJ Docker container
• Set OpenDJ password as specified for OpenDJ Docker container as well (password by default).

If you changed base DN for OpenDJ, set required Root Suffix as well.

Then press the Next button.

On the User datastore setting set OpenDJ password as has been set in the previous step and press the Next button.

If this instance is behind the load balancer, set the site configuratuin settings, if it's not, just press the Next button.

On the Step 6: Default Policy Agent User, enter and confirm default policy agent password and press the Next button.

Review configuration summary and press the Create Configuration button.

If everything is ok, proceed to login page.

If you have any additional questions, feel free to ask us!
