PHOBOS-NET

PHOBOS-NET is a self-hosted, read-only network observability platform designed for operators who value truth, clarity, and calm UX over automation and alert noise.

It combines NetFlow, OPNsense firewall logs, and SNMP into a single, explainable view of network behavior.

No blocking.
No enforcement.
No guessing.
Just accurate visibility.

---

Why PHOBOS-NET

PHOBOS-NET is intentionally conservative by design:

• Observational, not reactive
• Truth over completeness
• Signals ≠ alerts
• Health reflects operability, not attacks

If data is unavailable, PHOBOS-NET shows UNKNOWN / — instead of inferring values.

---

Core Capabilities

NetFlow Observation

• Flow-level visibility via nfdump
• Time-range aware queries (48h default)
• No flow deduplication or inference

Firewall Visibility (OPNsense)

• RFC-compliant filterlog parsing
• Normalized pass / block / reject events
• IPv4 and IPv6 support
• Separate syslog streams supported (UDP 514 / 515)

SNMP Monitoring (Required)

• CPU, memory, and interface metrics
• Authoritative counters (ifTable / ifXTable)
• Explicit availability tracking If WAN/LAN live widgets do not match the gateway labels, set SNMP_WAN_NAME / SNMP_LAN_NAME (or SNMP_WAN_IFINDEX / SNMP_LAN_IFINDEX).

Threat timeline persistence: recent threat activity is stored in /app/data/threat-timeline.json so threat panels survive container restarts. Override the path with THREAT_TIMELINE_PATH if needed. Alerts persist in /app/data/alerts.db (SQLite).

Health, Alerts & Indicators

• System Health reflects monitoring operability only
• Alerts require strict escalation and persistence
• Indicators provide context without triggering alarms

---

Quick Start (Docker Compose)

Dockerhub: https://hub.docker.com/r/legato3/phobos-net

The fastest way to deploy PHOBOS-NET is using Docker Compose. For a step-by-step walkthrough, see: docs/USER_GUIDE.md

1. Create docker-compose.yml:

services:
  phobos-net:
    image: legato3/phobos-net:latest
    container_name: phobos-net
    restart: unless-stopped
    ports:
      - "3434:8080"      # Web UI
    environment:
      - TZ=UTC # Set to your timezone
      - NFCAPD_INTERVAL=15
      - PHOBOS_ROLE=web
      - PHOBOS_DISABLE_BACKGROUND=1
      - PHOBOS_SHARED_STATE_DIR=/app/data/.shared
    volumes:
      - ./docker-data:/app/data
      - ./docker-data/nfdump:/var/cache/nfdump

  phobos-net-worker:
    image: legato3/phobos-net:latest
    container_name: phobos-net-worker
    restart: unless-stopped
    cap_add:
      - NET_RAW
    ports:
      - "514:5514/udp"   # Firewall Logs (OPNsense)
      - "515:5515/udp"   # App/Syslog
      - "2055:2055/udp"  # NetFlow (nfcapd)
    environment:
      - TZ=UTC # Set to your timezone
      - NFCAPD_INTERVAL=15
      - PHOBOS_ROLE=worker
      - PHOBOS_SHARED_STATE_DIR=/app/data/.shared
    volumes:
      - ./docker-data:/app/data
      - ./docker-data/nfdump:/var/cache/nfdump
    entrypoint: ["/app/docker-worker-entrypoint.sh"]

Minimum required settings

• TZ in compose
• OPNsense targets set (NetFlow + Syslog) to the worker ports
• SNMP Host + Community set in Settings (for Gateway widgets)
• NetFlow retention configurable in Settings (default 7 days)

If you’re on macOS/Windows (Docker Desktop): Privileged UDP ports can be unreliable. If syslog widgets stay empty, publish and target 5514/5515 instead:

  phobos-net-worker:
    ports:
      - "5514:5514/udp"
      - "5515:5515/udp"
      - "2055:2055/udp"

OPNsense targets (quick reference):

• NetFlow → <host-ip>:2055
• Syslog filterlog → <host-ip>:514 (or 5514 if using Docker Desktop workaround)
• Syslog app/system → <host-ip>:515 (or 5515 if using Docker Desktop workaround)

2. Launch:

docker compose config
docker compose up -d

First-Run Validation

PHOBOS-NET is observational; it needs data to show anything. Verify your setup in 5 steps:

1. Open UI & Login: Access http://localhost:3434.
   • Default Credentials: admin / phobos-net
   • Important: These are bootstrap credentials. Rotate them immediately in non-lab environments.
   • Use the top-right Operator menu to change the password after first login.
2. Configure SNMP: Open Settings (top-right) and set SNMP Host + SNMP Community to match OPNsense.
3. Configure Syslog Filter (Optional): On Linux Docker hosts, set Firewall IP (Syslog) to your firewall IP if you want to accept syslog only from that host. On Docker Desktop (macOS/Windows), keep it blank (or FIREWALL_IP=0.0.0.0) because UDP source IP may be rewritten before it reaches the container. If FIREWALL_IP is set in Docker, it overrides the UI.
4. Confirm Syslog: Go to the Firewall tab. If OPNsense is configured, you should see logs appearing within 60 seconds.
5. Confirm NetFlow: Go to the Network tab. By default nfdump rotates every 15 seconds; for live bandwidth, set OPNsense Active/Inactive timeouts to 15s/5s and set NFCAPD_INTERVAL=15 in your compose file.

---

OPNsense Configuration

SNMP, Syslog, and NetFlow must be configured on your gateway. See: docs/OPNSENSE_CONFIG.md

Production-Grade Guidance

For hardened deployments (worker split, TLS, backups, monitoring), see: docs/PRODUCTION_GRADE.md

If Widgets Are Empty

1. Check UDP ports from the firewall (2055, 514/515 or 5514/5515).
2. Check public liveness: curl http://localhost:3434/health
3. Check login page availability: curl -I http://localhost:3434/login
4. Check logs (both containers in split mode):
   • docker logs phobos-net --tail=200
   • docker logs phobos-net-worker --tail=200
5. If syslog is empty, verify Firewall IP (Syslog):
   • Linux Docker host: set it to your firewall source IP (or leave blank).
   • Docker Desktop (macOS/Windows): keep it blank or 0.0.0.0.
6. For live bandwidth, set OPNsense Active/Inactive timeouts to 15s/5s and NFCAPD_INTERVAL=15.

Compose Validation Error

If Compose reports additional properties 'phobos-net-worker' not allowed, the service is likely mis-indented.

• Ensure both phobos-net and phobos-net-worker are nested under services:.
• Validate before launching: docker compose config.

Docker Desktop Syslog Note

On macOS/Windows Docker Desktop, privileged UDP forwarding to host 514/515 can be unreliable.

• Prefer publishing worker ports 5514:5514/udp and 5515:5515/udp.
• Point OPNsense Syslog targets to <host-ip>:5514 and <host-ip>:5515.
• Keep FIREWALL_IP unset (or 0.0.0.0) on Docker Desktop. Docker may rewrite UDP source IP before container ingress, so strict source-IP filtering can block valid syslog packets.

Storage Note

NetFlow files can grow quickly. By default, PHOBOS-NET keeps 7 days of NetFlow files. Adjust with NETFLOW_RETENTION_DAYS (set to 0 to disable cleanup). You can still prune manually if needed:

find ./docker-data/nfdump -type f -mtime +7 -delete

---

Security Model

• Authentication Required: Dashboard pages and operational APIs require a valid session.
• Role-Based Access: Admins can create users and assign roles (admin, operator, viewer) from the Operator menu.
• Public Probe Endpoints: /health and /metrics are intentionally unauthenticated for container/orchestrator health checks.
• Bcrypt Hashing: Passwords are stored using industry-standard salted Bcrypt.
• Secure Headers: Strict Content Security Policy (CSP), HSTS, and XSS protection enabled by default.
• Non-Root Execution: Runs as a non-privileged user within Docker.
• Read-Only: No packet capture, no active response, no automated blocking.

---

Contributing

PHOBOS-NET welcomes contributors who value correctness and calm UX.

Please read:

• docs/CONTRIBUTING.md
• docs/SECURITY.md
• docs/AGENTS.md

---

License

MIT License
